Belden 8102.01152 Multipair Cable Computer Screened 2 Pair 24 AWG 0.2 mm² 498.69 ft 152.4 m
The 8102 060500 is a 500ft 2-pair 4-conductor low capacitance shielded Computer Cable with tinned copper conductors with foam high density polyethylene insulation. It has an outer shield of 100% aluminium foil-polyester tape with shorting fold coverage and 65% TC braid coverage.
- CPR: Eca
- 27.5lb Maximum recommended pulling tension
- 100R Impedance
- 1.8A at 25°C Current per conductor
- -30 to 80°C Operating temperature range
Computers & Computer Peripherals, Communications & Networking
Product details
| Cable Shielding | Screened |
| No. of Pairs | 2 Pair |
| Wire Gauge | 24AWG |
| Conductor Area CSA | 0.2mm² |
| Reel Length (Imperial) | 498.69ft |
| Reel Length (Metric) | 152.4m |
| Jacket Colour | Chrome |
| No. of Max Strands x Strand Size | 7 x 0.2mm |
| Voltage Rating | 300V |
| Jacket Material | PVC |
| Conductor Material | Tinned Copper |
| External Diameter | 6.9mm |
| Product Range | - |
Other details
| Brand | BELDEN |
| Part Number | 8102.01152 |
| Quantity | Reel of 152 |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
