BULGIN FX0416S Fuseholder, Panel Mount, 250V, 13A, 6.3 x 25mm, 4.8 Series Tabs, Screw Cap, Screwdriver, PC2
The FX0416S is a 16A/250V panel mount Cartridge Fuse Holder with black glass filled nylon body, brass/silver-plated contacts, nylon cap, polyester sleeve, solder lug termination and screw cap/screwdriver release fuse carrier. This fuse holder features protection category PC2 with integral protection against electric shock.
- 4W Maximum power dissipation (at 23°C)
- >10?MR at 500VDC Insulation resistance
- 4kV at 50Hz AC Breakdown
- <5mR Contact resistance
- -20 to 85°C Operating temperature range
- UL94V-0 Flammability rating
Applications
Safety
Product details
| Fuse Holder Type | Cartridge Fuse Holder |
| Voltage Rating V AC | 250V |
| Fuse Current | 16A |
| No. of Fuses | 1Fuses |
| Product Range | - |
| Holder Terminals | Quick Connect, Screw |
| Voltage Rating V DC | 250V |
| Fuse Size Held | 1/4" x 1", 6.3mm x 25.4mm, 8AG |
Other details
| Brand | BULGIN |
| Part Number | FX0416S |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
