COILCRAFT MOS6020-103MLC Surface Mount Power Inductor, MOS6020 Series, 10 �H, 2.2 A, 790 mA, Shielded, 0.092 ohm
This is a Surface Mount Power Inductor, MOS6020 Series, 10 �H, 2.2 A, 790 mA, Shielded, 0.092 ohm product from COILCRAFT with the model number MOS6020-103MLC
Product details
| Power Inductor Case | 6.8mm x 6mmx 2.4mm |
| DC Resistance Max | 0.092ohm |
| Saturation Current (Isat) | 790mA |
| Packaging | Cut Tape |
| Inductance Tolerance | � 20% |
| Product Range | MOS6020 Series |
| RMS Current (Irms) | 2.2A |
| Inductance | 10�H |
| Inductor Construction | Shielded |
Other details
| Brand | COILCRAFT |
| Part Number | MOS6020-103MLC |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
