Microchip TP2104N3-G Mosfet Transistor P Channel -175 mA -40 V 6 ohm -10 -2
This is a MOSFET Transistor, P Channel, -175 mA, -40 V, 6 ohm, -10 V, -2 V product from MICROCHIP with the model number TP2104N3-G
Product details
| Transistor Polarity | P Channel |
| Continuous Drain Current Id | -175mA |
| Drain Source Voltage Vds | -40V |
| On Resistance Rds(on) | 6ohm |
| Rds(on) Test Voltage Vgs | -10V |
| Threshold Voltage Vgs | -2V |
| Power Dissipation Pd | 740mW |
| Transistor Case Style | TO-92 |
| No. of Pins | 3Pins |
| Operating Temperature Max | 150°C |
| Product Range | - |
| Automotive Qualification Standard | - |
| RoHS Phthalates Compliant | To Be Advised |
| MSL | - |
Other details
| Brand | MICROCHIP |
| Part Number | TP2104N3-G |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
