MYRRA 44056 Isolation Transformer, 1 VA, 1 x 230V, 2 x 9V, 56 mA, PCB MOUNTED 44xxx Series
The 44000 series from Myrra are 50Hz PCB mount encapsulated transformers. These transformers are UL 5085, VDE, EN 61558-2-6, EN 60950 certified.
- Power rating ranges from 0.6VA to 30VA
- Available in 117VAC and 230VAC primary voltages
- Secondary voltage ranges from 6VAC to 2 x 24VAC
- UL 5085, VDE, EN 61558-2-6, EN 60950 certified
- Two compartments bobbins
- UL94-V0 approved self extinguishing plastic case
- IP 00 degree of protection
- Inherently short circuits proof
- Customized designs on specification
- 4KV insulation voltage
Applications
Industrial, Power Management
Product details
| Plug Type | - |
| Power Rating | 1VA |
| Isolation Transformer Primary Voltages | 1 x 230V |
| Current Rating | 56mA |
| Product Range | PCB MOUNTED 44xxx Series |
| Secondary Voltages | 2 x 9V |
Other details
| Brand | MYRRA |
| Part Number | 44056 |
| Quantity | Each |
| Technical Data Sheet EN |  |
