OMRON ELECTRONIC COMPONENTS G6B2014PUS5DC General Purpose Relay, G6B Series, Power, Non Latching, DPST-NC, 5 VDC, 5 A
Product details
| Contact Material | Silver Alloy |
| Relay Mounting | Through Hole |
| Coil Type | Non Latching |
| Coil Resistance | 83.3ohm |
| Product Range | G6B Series |
| Relay Terminals | Solder |
| Contact Current | 5A |
| Approvals & Standards | CSA, UL |
| Contact Voltage VAC | 250VAC |
| Coil Voltage | 5VDC |
| Contact Configuration | DPST-NC |
| Contact Voltage VDC | 30VDC |
Other details
| Brand | OMRON ELECTRONIC COMPONENTS |
| Part Number | G6B2014PUS5DC |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
