PANASONIC ELECTRONIC COMPONENTS EEUFR1J271 Electrolytic Capacitor, Low ESR, 270 µF, 63 V, FR Series, ± 20%, Radial Leaded, 12.5 mm

This is a Electrolytic Capacitor, Low ESR, 270 µF, 63 V, FR Series, ± 20%, Radial Leaded, 12.5 mm product from PANASONIC ELECTRONIC COMPONENTS with the model number EEUFR1J271

Product details

Capacitance	270µF
Voltage Rating	63V
Product Range	FR Series
Capacitance Tolerance	± 20%
Capacitor Terminals	Radial Leaded
Diameter	12.5mm
Packaging	Each
Lead Spacing	5mm
Height	20mm
Operating Temperature Min	-40°C
Operating Temperature Max	105°C
Lifetime @ Temperature	10000 hours @ 105°C
ESR	0.33ohm
Automotive Qualification Standard	-

Other details

Brand	PANASONIC ELECTRONIC COMPONENTS
Part Number	EEUFR1J271
Quantity	Each
Technical Data Sheet EN
