SCHNEIDER ELECTRIC RSL1PVBU General Purpose Relay, RSL Series, Interface, SPDT, 24 VDC, 6 A
This is a General Purpose Relay, RSL Series, Interface, SPDT, 24 VDC, 6 A product from SCHNEIDER ELECTRIC with the model number RSL1PVBU
Product details
| Contact Configuration | SPDT |
| Coil Voltage | 24VDC |
| Contact Current | 6A |
| Product Range | RSL Series |
| Relay Mounting | Socket |
| Coil Type | DC |
| Contact Voltage VAC | 250VAC |
| Relay Terminals | Quick Connect |
| Contact Voltage VDC | 24V |
| Contact Material | Silver Alloy |
| Coil Resistance | 3.39kohm |
| Approvals & Standards | - |
Other details
| Brand | SCHNEIDER ELECTRIC |
| Part Number | RSL1PVBU |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
$14.51
Original: $48.38
-70%SCHNEIDER ELECTRIC RSL1PVBU General Purpose Relay, RSL Series, Interface, SPDT, 24 VDC, 6 A—
$48.38
$14.51Product Information
