Texas Instruments MAX232DR MAX232DR Transceiver RS232 2 Drivers 4.5V-5.5V Supply SOIC-16
The MAX232D is a dual driver/receiver that includes a capacitive voltage generator to supply TIA/EIA-232-F voltage levels from a single 5V supply. Each receiver converts TIA/EIA-232-F inputs to 5V TTL/CMOS levels. These receivers have a typical threshold of 1.3V, a typical hysteresis of 0.5V, and can accept ±30V inputs. Each driver converts TTL/CMOS input levels into TIA/EIA-232-F levels. The driver, receiver, and voltage generator functions are available as cells in the Texas Instruments LinASIC library.
- Operates from a single 5V power supply with 1µF charge pump capacitors
- Operates up to 120kbit/s
- Two drivers and two receivers
- ±30V input levels
- Low supply current: 8mA typ.
Consumer Electronics, Industrial, Multimedia, Wireless
Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | MAX232DR |
| Quantity | Each (Supplied on Cut Tape) |
| Product Change Notice EN |  |
