TRACOPOWER TEN 25-4812WI Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 18 V, 75 V, 25 W, 12 V

This is a Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 18 V, 75 V, 25 W, 12 V product from TRACOPOWER with the model number TEN 25-4812WI

Product details

Output Power Max	25W
Input Voltage DC Min	18V
DC / DC Converter Mounting	Through Hole
Output Voltage - Output 2	-
Output Current - Output 2	-
Depth	50.8mm
Width	40.6mm
Product Range	TEN 25WI Series
DC / DC Converter Type	DIP
Approvals & Standards	IEC, UL
Output Voltage - Output 3	-
Output Voltage - Output 1	12V
Output Current - Output 3	-
No. of Outputs	1 Output
DC / DC Converter Output Type	Fixed, Adjustable
Input Voltage DC Max	75V
Output Current - Output 1	2.5A
Height	9.3mm

Other details

Brand	TRACOPOWER
Part Number	TEN 25-4812WI
Quantity	Each
Technical Data Sheet EN
