TRACOPOWER TEN 30-2432WIN Isolated Board Mount DC/DC Converter, Metal Case, 3 Output, 30 W, 5 V, 4 A, 15 V, 330 mA

This is a Isolated Board Mount DC/DC Converter, Metal Case, 3 Output, 30 W, 5 V, 4 A, 15 V, 330 mA product from TRACOPOWER with the model number TEN 30-2432WIN

Product details

No. of Outputs	3 Output
Output Power Max	30W
Output Voltage - Output 1	5V
Output Current - Output 1	4A
Output Voltage - Output 2	15V
Output Current - Output 2	330mA
Output Voltage - Output 3	-15V
Output Current - Output 3	330mA
Product Range	-
Input Voltage DC Min	9V
Input Voltage DC Max	36V
DC / DC Converter Output Type	Fixed
DC / DC Converter Type	DIP
DC / DC Converter Mounting	Through Hole
Approvals & Standards	-
Width	25.4mm
Height	10.2mm
Depth	50.8mm

Other details

Brand	TRACOPOWER
Part Number	TEN 30-2432WIN
Quantity	Each
Technical Data Sheet EN
Miscellaneous EN
Application Note EN
