TRACOPOWER TEN 50-2412WI Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 9 V, 36 V, 50 W, 12 V

This is a Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 9 V, 36 V, 50 W, 12 V product from TRACOPOWER with the model number TEN 50-2412WI

Product details

Output Power Max	50W
Input Voltage DC Min	9V
DC / DC Converter Mounting	Through Hole
Output Voltage - Output 2	-
Output Current - Output 2	-
Depth	50.8mm
Width	25.4mm
Product Range	TEN 50WI Series
DC / DC Converter Type	DIP
Approvals & Standards	CSA, IEC, UL
Output Voltage - Output 3	-
Output Voltage - Output 1	12V
Output Current - Output 3	-
No. of Outputs	1 Output
DC / DC Converter Output Type	Fixed, Adjustable
Input Voltage DC Max	36V
Output Current - Output 1	4.17A
Height	11mm

Other details

Brand	TRACOPOWER
Part Number	TEN 50-2412WI
Quantity	Each
Technical Data Sheet EN
