TRACOPOWER TMR 3-2423WI Isolated Board Mount DC/DC Converter, Regulated, 2 Output, 3 W, 15 V, 100 mA, -15 V, 100 mA

This is a Isolated Board Mount DC/DC Converter, Regulated, 2 Output, 3 W, 15 V, 100 mA, -15 V, 100 mA product from TRACOPOWER with the model number TMR 3-2423WI

Product details

No. of Outputs	2 Output
Output Power Max	3W
Output Voltage - Output 1	15V
Output Current - Output 1	100mA
Output Voltage - Output 2	-15V
Output Current - Output 2	100mA
Output Voltage - Output 3	-
Output Current - Output 3	-
Product Range	-
Input Voltage DC Min	9V
Input Voltage DC Max	36V
DC / DC Converter Output Type	Fixed
DC / DC Converter Type	SIP
DC / DC Converter Mounting	Through Hole
Approvals & Standards	IEC, UL
Width	9.2mm
Height	11.1mm
Depth	21.8mm

Other details

Brand	TRACOPOWER
Part Number	TMR 3-2423WI
Quantity	Each
Technical Data Sheet EN
Miscellaneous EN
Application Note EN
