TRACOPOWER TSRN 1-2433 Linear Regulator DC/DC Converter, Fixed, Through Hole, 1 Output, 3.3 V, 1 A
The TSRN 1-2433 is a 1-output Step-down Switching Regulator, suitable for positive or negative output circuits. It is a drop-in replacement for inefficient 78xx linear regulators. A high efficiency allows full load operation up to +70�C (+85�C with derating) ambient temperature without the need of any heat-sink or forced air cooling. It has better output accuracy (�2%), lower standby current of 2mA and no requirement of external capacitors.
- Over-temperature protection
- Short-circuit protection
- �0.015%/K Temperature coefficient
- 470�F Maximum capacitive load
- 300kHz Switching frequency
- Straight pins
- Excellent line/load regulation
Applications
Industrial
Product details
| Output Power Max | - |
| Input Voltage DC Min | 4.6V |
| DC / DC Converter Mounting | Through Hole |
| Product Range | - |
| Output Current Max | 1A |
| Approvals & Standards | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Output Voltage Nom. | 3.3V |
| Input Voltage DC Max | 42V |
Other details
| Brand | TRACOPOWER |
| Part Number | TSRN 1-2433 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
$5.05
Original: $16.84
-70%TRACOPOWER TSRN 1-2433 Linear Regulator DC/DC Converter, Fixed, Through Hole, 1 Output, 3.3 V, 1 A—
$16.84
$5.05Product Information
